Deep Groove Ball Bearings 6800 series

Product Name: Deep Groove Ball Bearings 6800 series
Model NO.: 6800, 6900 series
Origin: CHINA
Brand Name: Borine

Product Details: Deep Groove Ball Bearings 6800 series

Deep groove ball bearing is applied widely.It can be bear the radial and axial loading, suitable for high speed rotation.
Matric Size have 6000,6200,6300,6400,6800,6900,16000,62200,62300 series.
Other special ball bearing can be produced according to the samples or draws supplied by customers.

Deep Groove Ball Bearings

6800, 6900 (61800, 61900) series

Bearing Number	Bore d		Outer Diameter D		Width W		Basic Load Rating		Weight
Bearing Number	mm	in.	mm	in.	mm	in.	Dynamic Cr (N)	Static Cor (N)	kg
61801	12	0.4724	21	0.8268	5	0.1968	1143	725	0.013
61802	15	0.5906	24	0.9449	5	0.1968	1245	976	0.015
61803	17	0.6693	26	1.0236	5	0.1968	1347	939	0.015
61804	20	0.7874	32	1.2598	7	0.2756	2082	1429	0.020
61805	25	0.9843	37	1.4567	7	0.2756	2327	1735	0.022
61806	30	1.1811	42	1.6535	7	0.2756	2326	1837	0.026
61807	35	1.3780	47	1.8504	7	0.2756	2408	2041	0.030
61808	40	1.5748	52	2.0472	7	0.2756	2501	2245	0.034
61809	45	1.7717	58	2.2835	7	0.2756	6510	5600	0.040
61810	50	1.9685	65	2.5591	7	0.2756	6600	6100	0.057
61811	55	2.1654	72	2.8346	9	0.3543	9060	8450	0.083
61812	60	2.3622	78	3.0709	10	0.3937	9120	8750	0.106
61813	65	2.5591	85	3.3465	10	0.3937	11900	11500	0.130
61814	70	2.7559	90	3.5433	10	0.3937	12100	11900	0.140
61815	75	2.9528	95	3.7402	10	0.3937	12500	12900	0.150
61816	80	3.1496	100	3.9370	10	0.3937	12700	13300	0.160
61817	85	3.3465	110	4.3307	13	0.5118	18700	19000	0.245
61818	90	3.5433	115	4.5276	13	0.5118	19500	20500	0.258
61901	12	0.4724	24	0.9449	6	0.2362	2653	1398	0.011
61902	15	0.5906	28	1.1024	7	0.2756	3163	1855	0.017
61903	17	0.6693	30	1.1811	7	0.2756	3398	1949	0.018
61904	20	0.7874	37	1.4567	9	0.3543	5153	3153	0.036
61905	25	0.9873	42	1.6535	9	0.3543	5755	3755	0.049
61906	30	1.1811	47	1.8504	9	0.3543	5949	4051	0.051
61907	35	1.3780	55	2.1654	10	0.3937	7512	5408	0.080
61908	40	1.5748	62	2.4409	12	0.4724	8561	7051	0.120
61909	45	1.7717	68	2.6772	12	0.4724	14130	10860	0.128
61910	50	1.9685	72	2.8346	12	0.4724	14490	11730	0.140
61911	55	2.1654	80	3.1496	13	0.5118	15900	13200	0.180
61912	60	2.3622	85	3.3465	13	0.5118	16400	14230	0.193
61913	65	2.5591	90	3.5433	13	0.5118	17400	16000	0.206
61914	70	2.7559	100	3.9370	16	0.6299	23560	21500	0.334
61915	75	2.9528	105	4.1339	16	0.6299	24330	22540	0.353
61916	80	3.1496	110	4.3307	16	0.6299	24900	23900	0.440
61917	85	3.3465	120	4.7244	18	0.7087	31900	29700	0.536
61918	90	3.5433	125	4.9213	18	0.7087	32800	31500	0.554
