China Tapered Roller Bearings 32000 series,Tapered Roller Bearings 32000 series Manufacturer
Tapered Roller Bearing specially suitable for can bear radial laoding and single way axial loading,the loading capacity is larger. 32000 series.
Tapered Roller Bearings
Matric Size
32000 series
| Bearing Number | Boundary Dimensions (mm) | Basic Load Rating | Mass | |||||
| d | D | T | B | C | dynamic Cr (N) | static Cor (N) | (kg.) | |
| 32004X | 20 | 42 | 15 | 15 | 12 | 22900 | 15600 | 0.097 |
| 32005X | 25 | 47 | 15 | 15 | 11.5 | 25500 | 18600 | 0.114 |
| 32006X | 30 | 55 | 17 | 17 | 13 | 33600 | 24500 | 0.166 |
| 32007X | 35 | 62 | 18 | 18 | 14 | 40200 | 30500 | 0.224 |
| 32008X | 40 | 68 | 19 | 19 | 14.5 | 44500 | 40000 | 0.278 |
| 32009X | 45 | 75 | 20 | 20 | 15.5 | 55000 | 44000 | 0.346 |
| 32010X | 50 | 80 | 20 | 20 | 15.5 | 57200 | 48000 | 0.366 |
| 32011X | 55 | 90 | 23 | 23 | 17.5 | 76500 | 64000 | 0.563 |
| 32012X | 60 | 95 | 23 | 23 | 17.5 | 76500 | 67000 | 0.576 |
| 32013X | 65 | 100 | 23 | 23 | 17.5 | 78100 | 68000 | 0.630 |
| 32014X | 70 | 110 | 25 | 25 | 19 | 95200 | 83000 | 0.848 |
| 32015X | 75 | 115 | 25 | 25 | 19 | 99000 | 88000 | 0.909 |
| 32016X | 80 | 125 | 29 | 29 | 22 | 128000 | 116000 | 1.280 |
| 32017X | 85 | 130 | 29 | 29 | 22 | 130000 | 120000 | 1.350 |
| 32018X | 90 | 140 | 32 | 32 | 24 | 157000 | 146000 | 1.790 |
| 32019X | 95 | 145 | 32 | 32 | 24 | 157000 | 146000 | 1.830 |
| 32020X | 100 | 150 | 32 | 32 | 24 | 161000 | 150000 | 1.910 |
| 32021X | 105 | 160 | 35 | 35 | 26 | 190000 | 180000 | 2.420 |
| 32022X | 110 | 170 | 38 | 38 | 29 | 220000 | 208000 | 3.070 |
| 32024X | 120 | 180 | 38 | 38 | 29 | 229000 | 224000 | 3.250 |
| 32026X | 130 | 200 | 45 | 45 | 34 | 297000 | 290000 | 4.960 |
