Tapered Roller Bearings 32200 series

Product Name: Tapered Roller Bearings 32200 series
Model NO.: 32200 series
Origin: CHINA
Brand Name: Borine

Product Details: Tapered Roller Bearings 32200 series

Tapered Roller Bearing specially suitable for can bear radial laoding and single way axial loading,the loading capacity is larger. 32200 (7500) series.

Tapered Roller Bearings
Matric Size
32200 (7500) series

Bearing Number	Boundary Dimensions (mm)					Basic Load Rating		Mass
Bearing Number	d	D	T	B	C	dynamic Cr (N)	static Cor (N)	(kg.)
32205	25	52	19.25	18	16	34100	25000	0.187
32206	30	62	21.25	20	17	47300	33500	0.301
32207	35	72	24.25	23	19	61600	45000	0.457
32208	40	80	24.75	23	19	70400	50000	0.558
32209	45	85	24.75	23	19	74800	56000	0.607
32210	50	90	24.75	23	19	70400	52000	0.648
32211	55	100	26.75	25	21	99000	75000	0.876
32212	60	110	39.75	28	24	119000	91500	1.180
32213	65	120	32.75	31	27	142000	112000	1.580
32214	70	125	33.25	31	27	147000	118000	1.680
32215	75	130	33.25	31	27	151000	120000	1.740
32216	80	140	35.25	33	28	176000	137000	2.180
32217	85	150	38.5	36	30	201000	163000	3.750
32218	90	160	42.5	40	34	238000	193000	3.490
32219	95	170	45.5	43	37	264000	220000	4.300
32220	100	180	49	46	39	297000	250000	5.120
32221	105	190	53	50	43	341000	290000	6.250
32222	110	200	56	53	46	374000	325000	7.430
32224	120	215	61.5	58	50	440000	390000	9.080
32226	130	230	67.75	64	54	523000	475000	11.200
