4-Bolt Hole Square Self-Aligning Mounting Flanges

Product Name: 4-Bolt Hole Square Self-Aligning Mounting Flanges

Product Details: 4-Bolt Hole Square Self-Aligning Mounting Flanges

All Stamped Steel Mounting Flanges are for curved outer race bearings. May be mounted at any angle to provide a sturdy, compact housing for the bearing. Initial self-alignment is provided by the curved outer surface of the bearing which matches the curved inside surface of the flange mount. Flanges available in Round, Square, Triangular, 2-Hole, Pillow Block.

Stamped Steel Mounting Flanges
4-Bolt Hole Square Self-Aligning Mounting Flanges

Part Number	To Fit Shaft Size	A.	B.
80MS-S	1 1/2", 1 9/16"	4 3/4"	4 11/16"
85MS-S	1 5/8", 1 11/16", 1 3/4"	4 3/4"	4 3/4"
87MS-S	Square Bore 7/8", 1", 1 1/8"	4 3/4"	4 3/4"
90MS-S	1 13/16", 1 7/8", 1 15/16"	5 1/4"	5"
