GEG..ES, GEG..ES-2RS series

Product Name: GEG..ES, GEG..ES-2RS series

Product Details: GEG..ES, GEG..ES-2RS series

Spherical Plain Bearing is designed can bear radial loading,axial loading and combine loading.As the outer spherical raceway is inlaid some composite,so bearing can self-lubricate.It is supplied for the situation of low-speed swing.
Radial Spherical Plain Bearings
GEG..E(S), GEG..ES-2RS
◆ Out ring with single splitin axial direction
◆ Lubricating groove and holes in the Outer and Inner rings of type ES.
◆ Outer ring of type -2RS with Lip Seals in both sides.
◆ Both Outer Ring and Inner Ring are properly phosphate treated.

Bearing No.		Diamensions (mm)						Load Rating (KN)		Wt.
Bearing No.		d	D	B	C	dk	α (o)	Cr	Cor	(kg)
GEG 6 E		6	16	9	5	13	21	5.5	27.5	0.008
GEG 8 E		8	19	11	6	16	21	8.15	40.5	0.014
GEG 10 E		10	22	12	7	18	18	10.8	54	0.020
GEG 12 E		12	26	15	9	22	18	17	85	0.034
GEG 15 ES	GEG 15 ES-2RS	15	30	16	10	25	16	21.2	106	0.046
GEG 17 ES	GEG 17 ES-2RS	17	35	20	12	29	19	30	146	0.077
GEG 20 ES	GEG 20 ES-2RS	20	42	25	16	35.5	17	48	240	0.150
GEG 25 ES	GEG 25 ES-2RS	25	47	28	18	40.7	17	62	310	0.190
GEG 30 ES	GEG 30 ES-2RS	30	55	32	20	47	17	80	400	0.290
GEG 35 ES	GEG 35 ES-2RS	35	62	35	22	53	16	100	500	0.380
GEG 40 ES	GEG 40 ES-2RS	40	68	40	25	60	17	127	640	0.540
GEG 45 ES	GEG 45 ES-2RS	45	75	43	28	66	15	156	780	0.680
GEG 50 ES	GEG 50 ES-2RS	50	90	56	36	80	17	245	1220	1.400
GEG 60 ES	GEG 60 ES-2RS	60	105	63	40	92	17	315	1560	2.000
GEG 70 ES	GEG 70 ES-2RS	70	120	70	45	105	16	400	2000	2.900
GEG 80 ES	GEG 80 ES-2RS	80	130	75	50	115	14	490	2450	3.500
GEG 90 ES	GEG 90 ES-2RS	90	150	85	55	130	15	610	3050	5.400
GEG 100 ES	GEG 100 ES-2RS	100	160	85	55	140	14	655	3250	5.900
GEG 110 ES	GEG 110 ES-2RS	110	180	100	70	160	12	950	4750	9.600
GEG 120 ES	GEG 120 ES-2RS	120	210	115	70	180	16	1080	5400	15.100
GEG 140 ES	GEG 140 ES-2RS	140	230	130	80	200	16	1360	6800	19.010
GEG 160 ES	GEG 160 ES-2RS	160	260	135	80	225	16	1530	7650	24.700
