Cylindrical Roller Bearings

Product Name: Cylindrical Roller Bearings

Product Details: Cylindrical Roller Bearings

Cylindrical Roller Bearing is designed that the roller and the raceway is line-contact.With great radial loading capacity, smaller friction coefficient and higher speed, it is suitable for can be borne heavy duty and impulsive loading. Structures of various series: NU, NJ, NUP, N, NF series. The Cages can made of Brass or Steel.

Cylindrical Roller Bearings

NU, NJ, NUP, N, NF series

Product Images: Cylindrical Roller Bearings

Other Products

Cylindrical Roller Bearings

New Products

Cylindrical Roller Bearings

Dimensions (mm)			Bearing No.					Load Rating (KN)		Wt.
d	D	B	NU series	NJ series	NUP series	N series	NF series	Cr	Cor	(kg)
20	47	14	NU204	NJ204	NUP204	N204	NF204	16.6	13.9	0.111
	47	14	NU204E	NJ204E	NUP204E	-	-	25.7	22.6	0.122
	47	18	NU2204	NJ2204	NUP2204	N2204	-	22.2	20.3	0.144
	47	18	NU2204E	NJ2204E	NUP2204E	-	-	30.5	28.3	0.158
	52	15	NU304	NJ304	NUP304	N304	NF304	23.1	19.2	0.153
	52	15	NU304E	NJ304E	NUP304E	-	-	31.5	26.9	0.176
	52	21	NU2304	NJ2304	NUP2304	N2304	-	33	30	0.25
	52	21	NU2304E	NJ2304E	NUP2304E	-	-	42	39	0.242
25	47	12	NU1005	NJ1005	NUP1005	N1005	-	15.1	14.1	0.092
	52	15	NU205	NJ205	NUP205	N205	NF205	18.8	17	0.137
	52	15	NU205E	NJ205E	NUP205E	-	-	29.3	27.7	0.151
	52	18	NU2205	NJ2205	NUP2205	N2205	-	25.1	34.5	0.166
	52	18	NU2205E	NJ2205E	NUP2205E	-	-	35	34.5	0.186
	62	17	NU305	NJ305	NUP305	N305	NF305	31.5	27.7	0.241
	62	17	NU305E	NJ305E	NUP305E	-	-	41.5	37.5	0.275
	62	24	NU2305	NJ2305	NUP2305	N2305	-	46.5	45	0.343
	62	24	NU2305E	NJ2305E	NUP2305E	-	-	57	56	0.386
	80	21	NU405	NJ405	NUP405	N405	NF405	46.5	40	0.55
30	55	13	NU1006	NJ1006	NUP1006	N1006	-	19.7	19.6	0.13
	62	16	NU206	NJ206	NUP206	N206	NF206	24.9	23.3	0.207
	62	16	NU206E	NJ206E	NUP206E	-	-	39	37.5	0.226
	62	20	NU2206	NJ2206	NUP2206	N2206	-	35	36	0.261
	62	20	NU2206E	NJ2206E	NUP2206E	-	-	49	50	0.297
	72	19	NU306	NJ306	NUP306	N306	NF306	38.5	35	0.358
	72	19	NU306E	NJ306E	NUP306E	-	-	53	50	0.398
	72	27	NU2306	NJ2306	NUP2306	N2306	-	51.5	51	0.513
	72	27	NU2306E	NJ2306E	NUP2306E	-	-	74.5	77.5	0.58
	90	23	NU406	NJ406	NUP406	N406	NF406	62.5	55	0.751
35	62	14	NU1007	NJ1007	NUP1007	N1007	-	22.6	23.2	0.179
	72	17	NU207	NJ207	NUP207	N207	NF207	35.5	34	0.295
	72	17	NU207E	NJ207E	NUP207E	-	-	50.5	50	0.327
	72	23	NU2207	NJ2207	NUP2207	N2207	-	52	55.5	0.404
	72	23	NU2207E	NJ2207E	NUP2207E	-	-	61.5	65.5	0.455
	80	21	NU307	NJ307	NUP307	N307	NF307	49.5	47	0.461
	80	21	NU307E	NJ307E	NUP307E	-	-	71	71	0.545
	80	31	NU2307	NJ2307	NUP2307	N2307	-	64.5	65.5	0.712
	80	31	NU2307E	NJ2307E	NUP2307E	-	-	99	109	0.78
	100	25	NU407	NJ407	NUP407	N407	NF407	75.5	69	0.99
40	68	15	NU1008	NJ1008	NUP1008	N1008	-	27.3	29	0.22
	80	18	NU208	NJ208	NUP208	N208	NF208	43.5	43	0.378
	80	18	NU208E	NJ208E	NUP208E	-	-	55.5	55.5	0.426
	80	23	NU2208	NJ2208	NUP2208	N2208	-	58	62	0.49
	80	23	NU2208E	NJ2208E	NUP2208E	-	-	72.5	77.5	0.552
	90	23	NU308	NJ308	NUP308	N308	NF308	58.5	57	0.658
	90	23	NU308E	NJ308E	NUP308E	-	-	83	81.5	0.754
	90	33	NU2308	NJ2308	NUP2308	N2308	-	82.5	88	0.951
	90	33	NU2308E	NJ2308E	NUP2308E	-	-	114	122	1.06
	110	27	NU408	NJ408	NUP408	N408	NF408	95.5	89	1.3
45	75	16	NU1009	NJ1009	NUP1009	N1009	-	31	34	0.28
	85	19	NU209	NJ209	NUP209	N209	NF209	46	47	0.432
	85	19	NU208E	NJ209E	NUP209E	-	-	63	66.5	0.495
	85	23	NU2209	NJ2209	NUP2209	N2209	-	61	68	0.53
	85	23	NU2209E	NJ2209E	NUP2209E	-	-	76	84.5	0.6
	100	25	NU309	NJ309	NUP309	N309	NF309	79	77.5	0.877
	100	25	NU309E	NJ309E	NUP309E	-	-	97.5	98.5	0.996
	100	36	NU2309	NJ2309	NUP2309	N2309	-	106	113	1.27
	100	36	NU2309E	NJ2309E	NUP2309E	-	-	137	153	1.41
	120	29	NU409	NJ409	NUP409	N409	NF409	115	112	1.62
50	80	16	NU1010	NJ1010	NUP1010	N1010	-	32	36	0.295
	90	20	NU210	NJ210	NUP210	N210	NF210	50.5	54.5	0.47
	90	20	NU210E	NJ210E	NUP210E	-	-	66	72	0.54
	90	23	NU2210	NJ2210	NUP2210	N2210	-	67.5	78.5	0.571
	90	23	NU2210E	NJ2210E	NUP2210E	-	-	79.5	91.5	0.652
	110	27	NU310	NJ310	NUP310	N310	NF310	87	86	1.14
	110	27	NU310E	NJ310E	NUP310E	-	-	110	113	1.3
	110	40	NU2310	NJ2310	NUP2310	N2310	-	121	131	1.7
	110	40	NU2310E	NJ2310E	NUP2310E	-	-	163	187	1.9
	130	31	NU410	NJ410	NUP410	N410	NF410	139	136	2.02
55	90	18	NU1011	NJ1011	NUP1011	N1011	-	37.5	44	0.442
	100	21	NU211	NJ211	NUP211	N211	NF211	61	66.5	0.638
	100	21	NU211E	NJ211E	NUP211E	-	-	82.5	93	0.718
	100	25	NU2211	NJ2211	NUP2211	N2211	-	79	93	0.773
	100	25	NU2211E	NJ2211E	NUP2211E	-	-	97	114	0.968
	120	29	NU311	NJ311	NUP311	N311	NF311	111	111	1.45
	120	29	NU311E	NJ311E	NUP311E	-	-	137	142	1.65
	120	43	NU2311	NJ2311	NUP2311	N2311	-	148	162	2.17
	120	43	NU2311E	NJ2311E	NUP2311E	-	-	201	233	2.37
	140	33	NU411	NJ411	NUP411	N411	NF411	139	138	2.48
60	95	18	NU1012	NJ1012	NUP1012	N1012	-	40	48.5	0.474
	110	22	NU212	NJ212	NUP212	N212	NF212	72	80	0.818
	110	22	NU212E	NJ212E	NUP212E	-	-	97.5	107	0.923
	110	28	NU2212	NJ2212	NUP2212	N2212	-	101	123	1.06
	110	28	NU2212E	NJ2212E	NUP2212E	-	-	131	157	1.21
	130	31	NU312	NJ312	NUP312	N312	NF312	124	126	1.8
	130	31	NU312E	NJ312E	NUP312E	-	-	150	157	2.05
	130	46	NU2312	NJ2312	NUP2312	N2312	-	169	188	2.71
	130	46	NU2312E	NJ2312E	NUP2312E	-	-	222	262	2.96
	150	35	NU412	NJ412	NUP412	N412	NF412	167	168	3
65	100	18	NU1013	NJ1013	NUP1013	N1013	-	41	51	0.485
	120	23	NU213	NJ213	NUP213	N213	NF213	84	94.5	1.02
	120	23	NU213E	NJ213E	NUP213E	-	-	108	119	1.21
	120	31	NU2213	NJ2213	NUP2213	N2213	-	120	149	1.4
	120	31	NU2213E	NJ2213E	NUP2213E	-	-	149	181	1.6
	140	33	NU313	NJ313	NUP313	N313	NF313	135	139	2.23
	140	33	NU313E	NJ313E	NUP313E	-	-	181	191	2.54
	140	48	NU2313	NJ2313	NUP2313	N2313	-	188	212	3.27
	140	48	NU2313E	NJ2313E	NUP2313E	-	-	248	287	3.48
	160	37	NU413	NJ413	NUP413	N413	NF413	195	203	3.6
70	110	20	NU1014	NJ1014	NUP1014	N1014	-	58.5	70.5	0.699
	125	24	NU214	NJ214	NUP214	N214	NF214	87.5	101	1.12
	125	24	NU214E	NJ214E	NUP214E	-	-	119	137	1.3
	125	31	NU2214	NJ2214	NUP2214	N2214	-	125	160	1.47
	125	31	NU2214E	NJ2214E	NUP2214E	-	-	156	194	1.7
	150	35	NU314	NJ314	NUP314	N314	NF314	158	168	2.71
	150	35	NU314E	NJ314E	NUP314E	-	-	205	222	3.1
	150	51	NU2314	NJ2314	NUP2314	N2314	-	223	262	3.98
	150	51	NU2314E	NJ2314E	NUP2314E	-	-	274	325	4.25
	180	42	NU414	NJ414	NUP414	N414	NF414	243	257	5.24
75	115	20	NU1015	NJ1015	NUP1015	N1015	-	60	74.5	0.738
	130	25	NU215	NJ215	NUP215	N215	NF215	101	118	1.23
	130	25	NU215E	NJ215E	NUP215E	-	-	130	156	1.41
	130	31	NU2215	NJ2215	NUP2215	N2215	-	136	172	1.55
	130	31	NU2215E	NJ2215E	NUP2215E	-	-	162	207	1.79
	160	37	NU315	NJ315	NUP315	N315	NF315	190	205	3.28
	160	37	NU315E	NJ315E	NUP315E	-	-	240	263	3.74
	160	55	NU2315	NJ2315	NUP2315	N2315	-	274	325	4.87
	160	55	NU2315E	NJ2315E	NUP2315E	-	-	330	395	5.25
	190	45	NU415	NJ415	NUP415	N415	NF415	262	274	6.22
80	125	22	NU1016	NJ1016	NUP1016	N1016	-	72.5	90.5	0.98
	140	26	NU216	NJ216	NUP216	N216	NF216	111	130	1.5
	140	26	NU216E	NJ216E	NUP216E	-	-	139	167	1.67
	140	33	NU2216	NJ2216	NUP2216	N2216	-	154	198	1.93
	140	33	NU2216E	NJ2216E	NUP2216E	-	-	186	243	2.12
	170	39	NU316	NJ316	NUP316	N316	NF316	201	223	3.86
	170	39	NU316E	NJ316E	NUP316E	-	-	256	282	4.22
	170	58	NU2316	NJ2316	NUP2316	N2316	-	274	330	5.79
	170	58	NU2316E	NJ2316E	NUP2316E	-	-	355	430	6.25
	200	48	NU416	NJ416	NUP416	N416	NF416	299	315	7.32
85	130	22	NU1017	NJ1017	NUP1017	N1017	-	74.5	95.5	1.03
	150	28	NU217	NJ217	NUP217	N217	NF217	126	149	1.87
	150	28	NU217E	NJ217E	NUP217E	-	-	167	199	2.11
	150	36	NU2217	NJ2217	NUP2217	N2217	-	178	232	2.44
	150	36	NU2217E	NJ2217E	NUP2217E	-	-	217	279	2.68
	180	41	NU317	NJ317	NUP317	N317	NF317	225	247	4.54
	180	41	NU317E	NJ317E	NUP317E	-	-	291	330	4.81
	180	60	NU2317	NJ2317	NUP2317	N2317	-	315	380	6.7
	180	60	NU2317E	NJ2317E	NUP2317E	-	-	395	485	7.16
	210	52	NU417	NJ417	NUP417	N417	NF417	335	350	9.4
90	140	24	NU1018	NJ1018	NUP1018	N1018	-	88	114	1.33
	160	30	NU218	NJ218	NUP218	N218	NF218	152	178	2.3
	160	30	NU218E	NJ218E	NUP218E	-	-	182	217	2.44
	160	40	NU2218	NJ2218	NUP2218	N2218	-	207	265	3.1
	160	40	NU2218E	NJ2218E	NUP2218E	-	-	242	315	3.33
	190	43	NU318	NJ318	NUP318	N318	NF318	240	265	5.3
	190	43	NU318E	NJ318E	NUP318E	-	-	315	355	5.72
	190	64	NU2318	NJ2318	NUP2318	N2318	-	325	395	7.95
	190	64	NU2318E	NJ2318E	NUP2318E	-	-	435	535	8.56
	225	54	NU418	NJ418	NUP418	N418	NF418	275	400	11.2
95	145	24	NU1019	NJ1019	NUP1019	N1019	-	90.5	120	1.4
	170	32	NU219	NJ219	NUP219	N219	NF219	166	195	2.78
	170	32	NU219E	NJ219E	NUP219E	-	-	220	265	3.02
	170	43	NU2219	NJ2219	NUP2219	N2219	-	230	298	3.79
	170	43	NU2219E	NJ2219E	NUP2219E	-	-	286	370	4.14
	200	45	NU319	NJ319	NUP319	N319	NF319	274	310	6.13
	200	45	NU319E	NJ319E	NUP319E	-	-	335	385	6.62
	200	67	NU2319	NJ2319	NUP2319	N2319	-	395	495	9.2
	200	67	NU2319E	NJ2319E	NUP2319E	-	-	460	585	9.8
	240	55	NU419	NJ419	NUP419	N419	NF419	400	445	13.2
100	150	24	NU1020	NJ1020	NUP1020	N1020	-	93	126	1.45
	180	34	NU220	NJ220	NUP220	N220	NF220	183	217	3.33
	180	34	NU220E	NJ220E	NUP220E	-	-	249	305	3.66
	180	46	NU2220	NJ2220	NUP2220	N2220	-	258	340	4.57
	180	46	NU2220E	NJ2220E	NUP2220E	-	-	335	445	5.01
	215	47	NU320	NJ320	NUP320	N320	NF320	315	365	7.49
	215	47	NU320E	NJ320E	NUP320E	-	-	380	425	8.57
	215	73	NU2320	NJ2320	NUP2320	N2320	-	460	590	11.7
	215	73	NU2320E	NJ2320E	NUP2320E	-	-	570	715	12.8
	250
